DISI MZR Timing Tool Kit and Camshafts Combo

List price:$679.98 Ā
Price: $605.58
You save: $74.40Ā (11%)
Price in points: What are Points?606 points
Save $74.40
Time your 2.3L Mazdaspeed DISI engine with confidence.
GEN-6-508-99

We know that when replacing a timing chain or doing other upgrades that require you to time your 2.3L DISI MZR engine, a good timing kit is necessary. That’s why we wanted to provide a kit that will get the job done and make the process straightforward to get you back out driving ASAP. The CS Timing kit provides the tools needed to accurately set your motor at TDC and to line up the intake and exhaust cams, ensuring that everything is in place when tightening down the cam gears. Check out the features of the Speed Timing Kit below

If you need specific details about the Mazdaspeed Cams or the Speed Timing Tools give them a click and Read up on them.

Mazdaspeed upgraded camshafts

Mazdaspeed Performance Camshafts

We chose to include two aluminum crankshaft timing pins in the CS timing kit just in case one gets left in and damaged during the process. We did this so that you don’t have to go out and buy another kit just to get another timing pin. Arguably the best feature of the timing kit is the included bottle opener that is built into the cam gauge. This was an important feature for us to include because we know that after this job, you’ll more than likely want something cold to drink like we do.



Mazdaspeed Camshaft Timing Kit Tools

Mazdaspeed Engine Timing Tools

The two included timing pins in the kit are made from 6061-T6 aluminum. We selected aluminum so that if the pin is left in, it won’t harm the engine, but will instead damage the pin. We also chose to anodize the pin in a bright red to make sure it doesn’t get overlooked and remain installed after the motor has been timed.

For the camshaft alignment plate we decided to go with 1/4" 304 Stainless Steel to ensure strength and to also make sure that it will always look as good as it did when it was brand new. The cam pockets are precisely machined to establish a tight and accurate fit when lining up your cams so that they will be spot on when you go to torque down the cam gear bolts.



  • Failure to remove the crankshaft timing pin after the cams have been timed can cause engine damage.
  • Do not use the crankshaft timing pin or cam alignment plate to hold the cams or crank in place when tightening the crankshaft pulley or cam gears.
  • OEM Mazda VVT Kit parts do not come with a warranty.
  • Stated warranty is for CorkSport Branded Timing Tool and or CorkSport CAMs only.

Additional Features

  • Vehicle Fitment:2007-2013 Mazdaspeed 3, 2006-2007 Mazdaspeed 6, 2007-2012 Mazda CX-7 Turbo.
  • Designed & Developed in America: Designed, tested, and validated in Vancouver, Washington, in the Pacific Northwest.
  • CorkSport Service & Support: Receive a 2-year warranty on timing tool kit ONLY, full-color installation instructions, all of the needed installation hardware, and knowledgeable telephone installation support at(360) 260-2675.



How To Set the Timing for your Mazdaspeed Disi Engine

It will take you 5-8 hours with our step-by-step instructions.

5-8 Hours Install Time

5-8 Hours Install Time

Difficulty: 5/5

5/5 Difficulty

2-Year Warranty

2-Year Warranty

No CEL

No CEL

2007-2013 Mazdaspeed 3 camshaft timing tool kit

No FAQ found

Mazda performance parts financing is available with CorkSport

Looking to finance your parts purchase and want to get 6 months NO interest on any purchase over $199? Click on the image above for more details.

Fits:
2007-2009 Mazdaspeed 3
2010-2013 Mazdaspeed 3
2007-2012 Cx7 Turbo
2006-2007 Mazdaspeed 6
2007-2009 Mazda 3 MPS
2010-2013 Mazda 3 MPS
2005-2007 Mazda 6 MPS
